Ashdown Engineering

AA-WOODSMAN-CLASSIC

$323.00
Elevate your acoustic performances with the NEW Woodsman Acoustic Range from Ashdown Engineering. Built upon a rich heritage of acoustic amp design, these amplifiers set new standards in vocal and instrument performance. Crafted for acoustic musicians, the Woodsman family combines timeless wooden cabinets with modern capabilities for both live shows and recording sessions.

With dedicated inputs for microphones and acoustic guitars, Woodsman amplifiers are tailored to solo singer/guitarists and duos. They provide pristine, clear acoustic tones and essential performance adjustments, including notch filters for feedback elimination. The 40W Classic model takes it a step further by adding a Tone control for the Mic Channel, Active and Passive inputs for the guitar channel, a phase reversal switch, notch filter, and an XLR DI out for seamless recording or PA system connectivity.
Please Note:
Direct purchases NOT available in the United States
Find your local Ashdown Dealer HERE

SPECIFICATIONS

  • Power Output - 40 Watts
  • Speaker Configuration - 1 x 8
  • Frequency Response - -3dB @ 28Hz and 28Hz
  • High Instrument Input - Impedance 10k Ohms, input range 300mV - 20V p-p
  • Low Instrument Input - Impedance 3.9M Ohms, input range 150mV - 10V p-p
  • Line Input - 10k Ohms Level 0dBu
  • Line Output - 4.7k Ohms Level 0dBu
  • Signal to Noise - Greater than 80dB (EQ Flat)
  • EQ - +/-15dB @ 100Hz and 10kHz
  • Effects Send - 10k Ohms Level 0dBu
  • Distortion - Less than 0.8% THD
  • H x W x D (mm) - 326 x 350 x 225
  • Weight (kg) - 8.54
Designed for acoustic performers, Ashdown Engineering announce the Woodsman family of amplifiers, combining traditional, beautiful wooden cabinets with powerful modern features for live performance and recording.

With inputs for microphones and acoustic guitar, Woodsman amps are ideal for duos, or solo singer/guitar players, delivering pure clear, acoustic tone and essential performance tuning features, including feedback eliminating notch filters.
“Ashdown has had a long tradition of creating great amplifiers for acoustic performers. With this latest range we’ve designed amps that deliver superb sound for a new generation of acoustic guitarists and singers and deliver the features they need at a new level of affordability.” – Mark Gooday
The 40W Classic model builds on the Parlour, adding a Tone control for the Mic Channel, Active and Passive inputs on the guitar channel, phase reversal switch, notch filter and an XLR DI out for recording or connecting to a PA.
