Acoustic 100
The AA-100 Wood is a twin channel 100 watt acoustic amplifier designed to be super portable and lightweight for the acoustic player on the go who needs it all.
Hand built in the UK Custom Shop the AA-100 Wood features a hand crafted wood cabinet and Custom designed Italian Sica speakers.
Both channels feature input level control and two band EQ(Bass and Treble). There are Hi and Low inputs plus an XLR balanced input with phantom power to connect a variety of instruments or a microphone with the minimum of fuss.
Stunning reverb comes in four flavours and a notch filter helps tame unwanted frequencies/feedback when playing at higher volume. A mini jack input with level control allows the user to play along to backing tracks and a balanced XLR DI output means the AA-100 can easily be linked to a PA if required. There is also a standard jack line out and FX send and return sockets.
The stunning Acoustic tones are delivered via a custom Italian Sica 1x8" driver combined with a studio quality horn for a lucious full range tone. The clever top mounted port also neatly doubles as a carry handle.
Features;
- Compact and portable weighing only 12kg
- 2 Channels with independent input levels
- 100 Watts
- 2 x Jack plus XLR input with Phantom Power
- Belton Block Digital Reverb
- Balanced XLR DI Output
- MP3 Mini Jack input with level control
- FX Send and Return
- 1x8" Italian Sica Driver plus studio quality horn
- Hand built and stained wood cabinet
- Built in UK Custom Shop
Specification
Power Output | 100 Watt |
Power Requirement | 230/115V |
Speaker Configuration | 8 |
Frequency Response | -3dB at 28Hz and 28Khz |
High Instrument Input | Channel 1 Active Impedance 3.9m Ohms, input range 300mV - 20mV p-p |
Low Instrument Input | Channel 1 Passive Impedance 3.9M Ohms, input range 150mV - 10V p-p |
Line Input | Impedance 10K Ohms, input level 0dBu nominal |
Line Output | Impedance 4.7K Ohms, Level 0dBu nominal |
DI Output | 600 Ohms balanced, -20dBu level nominal |
Impedance | Not Applicable |
Output Impedance | Not Applicable |
Signal to Noise | Better than 80dB (EQ Flat) |
EQ |
Bass +/-15dB @ 100Hz Treble +/-15dB @ 10kHz |
Effects Send | Impedance 10k Ohm, level 0dBu nominal |
Pre-amp Tubes | not applicable |
Output Tubes |
not applicable |
Distortion | Distortion less than 0.8% THD |
H x W x D (mm) |
410 x 300 x 320 |
Weight (kg) | 12 |
