Ashdown Triple Shot


In September 2023, Ashdown proudly presents the NEW Ashdown Triple Shot blended drive pedal. Tired of compromising your bass guitar distortion? The Triple Shot offers uncompromising high-gain bass overdrive, granting you complete mastery over your overdriven tones. Imagine having three distinct distortion pedals in one sleek unit.

With separate controls for "Dark," "Medium," and "Light" frequencies, you can sculpt your sound precisely, from thick and chunky lows to high-gain trebles. Whether you need a subtle mid-range boost or a roaring overdriven bass sound, the Triple Shot delivers. Its sensitivity means even subtle tweaks can create a world of difference. The Ashdown Triple Shot is the ultimate tool for crafting your unique drive sound.

Please Note:

Direct purchases NOT available in the United States

Find your local Ashdown Dealer HERE


  • Power Requirements - 9 Volt. Power Required
  • H x W x D (mm) - 145.50 x 116.20 x 65
  • Weight (kg) - 1.15
In essence, the Triple Shot is three individual distortion pedals in one! The signal from the instrument is split into three distinct frequency bands (“Dark”, “Medium” and “Light”) and fed into three distortion generators.

Each band has its own level (“Roast”) control before being recombined to create a full signal. It is therefore possible to retain and enhance the low-end frequencies of your bass sound with a thick and chunky overdriven tone, enrich
the top-end with high-gain trebles — or take the two extremes and mix them together to harvest a vast selection of distinct sonic qualities.
With all of the ‘Roast’ controls set all the way to the left, it’s
a simple, independent EQ… but using each of the Roast controls in harmony with its corresponding Dark, Medium or Light control, then you can vary the drive from a light little tickle in the mid-range to a full-on overdriven bass sound.
With all the controls at 12 o’clock you get a rich driven bass
sound that cuts above the mix in a live ‘alternative rock’ situation, whilst retaining the bottom end over your original bass signal. The pedal’s rotary controls are extremely sensitive, and a slight adjustment can mean a major
characterise change in sound. As a result, you have the ultimate control over your drive sound.
The pedal requires a minimum of 9v with 45ma draw centre pin negative (power supply not included).

Triple Shot, Blended Drive
User Manual
