AAA EVO 100 BT Demo
Alberto Rigoni takes the all NEW Ashdown AAA 100 BT combo through its paces
Specifications
Power Output | 100 Watts |
Speaker Configuration | 1 x 12” + HF Tweeter |
Speaker Outputs | 1/4" Jack |
Frequency Response | -3db at 22hz and 25khz |
High Instrument Input | Impedance - 3.9M Ohm Input range 150mv to 20v p - p |
Low Instrument Input | Impedance - 10k Ohm Input range 300mv to 40v p - p |
Line/BT Input | Yes with mix control |
DI Output | Balanced XLR |
Impedance | 8 Ohm. Minimum 4 Ohm when extension cab added |
EQ | Bass, Middle and Treble |
Effects Send | N/A |
Effects Return | N/A |
H x W x D (mm) | 420 x 410 x 325 |
Weight (kg) | 14 |
Resources

AAA EVO 100-BT User Manual
